Display

Panel Size

17" ( 5:4 )

Resolution

1280 x 1024

Display Brightness

400 cd/m2

Contrast Ratio

1000:1

Backlight Lifetime

50000 Hr (min.)

Viewing Angle

80 / 80 / 70 / 70 ( CR≥10) ( L / R / U / D )

Touch screen

Touch Type

10 point PCAP

Surface Hardness

≥7H

I / O

Video

1 x Waterproof Connector For H-DMI / VGA ( Optional )

USB

1 x SP13 Waterproof Connector For Touch USB2.0

Other I/O Interface

1 x Power Switch

Power

Power Adapter

1 x Optional AC/DC 12V/5A , 60W

Power Input

1 x SP13 Waterproof Connector For 12V~24V DC

Power Consumption

≦30W

Physical

Material

Aluminum Alloy Shell

Mounting

Stand / Wall / VESA

Dimension (W x H x D）

393 x 325 x 42 mm

Cut-out Size

 /

Packing Size

500 x 180 x 450 mm

Weight (Net)

4.5 kg

Environment

Operating Temperature

-20~70°C  ( -4~158°F )

Storage Temperature

-30~80°C (-22~176°F)

Relative Humidity

5%~95%@40°C, non-condensing

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

IP66 / IP69K

EMC

CE, FCC，Class A，ROHS

ORDERING INFORMATION

AVAILABLE MODELS

DESCRIPTION

WPM-H017SAC

17”SXGA LCD / Resolution 1280x1024 / PCAP Touch / 1 x H-DMI / 1 x T-USB / DC IN 12V~24V

PACKING LIST

1 x 17”Waterproof Touch Monitor

1 x 60W PSU (Power Supply)

1 x SP13 Waterproof H-DMI Cable 2M

1 x SP13 Waterproof T-USB Cable 2M
